Remesh while holding Boundary edges, edge angles, and other characteristic edges
It is useful for re-meshing meshes extracted from high poly and geometry generated from Cloth, Text and Vector Curves data.
gumroad
Remesh a mesh with Boundary edgesYou can remesh while holding open edges, edge angles, and other characteristic edges.It is useful for re-meshing meshes extracted from high poly and geometry generated from cloth, text and...
Price: USD 0.0
Property >Mesh Data >Remesh >Boundary Aligned Remesh
3D View >Sculpt >Remesh >Boundary Aligned Remesh
3D View >Right Mouse Click Menu >Boundary Aligned Remesh
Remove 2 side vertices
Reduce the polygons on the border
Prioritize less polygons over maintaining complete boundaries
Feature edge retention may not be fully retained
Transfer UV
Preserve UVs using a mesh transfer modifier
mirror
Use the mirror modifier to mirror after remeshing
X/Y/Z axis mirrors are available
Prevents remeshing by separating the specified edges in advance
Edge angle
Selected edge
Seam
sharp
Bevel weight
Crease
This add-on is a version derived from the add-on created by Jean Da Costa. Boundary Aligned Remesh ver1.0.0-Github
Contribute to jeacom25b/blender-boundary-aligned-remesh development by creating an account on GitHub.
I saw people sharing stuff about triangle meshes, cloth simulation, so I had to give my small contribution.
I made this addon last night.
The algorithm is quite simple and very similar to the one used on Toporake, feel free to use and adapt the code as you want.
boundary_alinged_remesh.py (6.8 KB)
Changes from ver1.0.0
Made it work on meshes without open edges
Rectangle option enabled by default
Added the menu
Changed operator property to scene property
Added many options
Topology quality is lower than voxel remesh
It works for meshes without open edges, but in some cases it may not work properly
忘却まとめ(日本語)
20 Likes
wilBr
August 5, 2020, 9:28pm
2
great enhancements, I’m using original boundary aligned remesh for terrain meshes, sometimes I’m getting random splited vertex/edges inside middle mesh… I’ll try your version… nice this working for non opened meshes too.
Albertofx
August 7, 2020, 12:11am
3
Awesome stuff. You made it work on 3d models
1 Like
Lamia
January 31, 2021, 5:20am
4
Hey great addon, right click seems to be broken with this addon, using 2.93.
1 Like
JR3D
September 12, 2024, 2:37pm
5
Hi, it would be really cool to have Boundary Aligned Remesh available on the new extensions platform, any plans?
